Ünmak UAT series accumulation tanks are designed for storage purpose of hot water from central heating system, floor heating system, geothermal or solar energy heating system by keeping the heat loss in minimum. Heating element installation is available for water heating purpose.
Accumulation Tank ÜAT series,
- It is upright type.
- It takes up little space.
- Hygiene is ensured by applying wet enamel on the interior surface coating.
- It is long lasting.
- It is hygienic.
- It is stylish and aesthetic with its modern design.
- It is highly efficient.
- Provides cathodic protection with magnesium anode.
- It has a thermometer.
- It can be supported with a heater upon request.
- Operating pressure is 10 bar.
- It is insulated with polyurethane.
- It looks stylish with its zippered vinyl cover with sponge insert.
| TECHNICAL FEATURES |
| PRODUCT TYPE |
ÜAT-100 |
ÜAT-160 |
ÜAT-200 |
ÜAT-300 |
ÜAT-500 |
ÜAT-800 |
ÜAT-1000 |
ÜAT-1500 |
ÜAT-2000 |
ÜAT-2500 |
ÜAT-3000 |
ÜAT-4000 |
ÜAT-5000 |
| Rated Volume |
Lt |
100 |
160 |
200 |
300 |
500 |
800 |
1.000 |
1.500 |
2.000 |
2.500 |
3.000 |
4.000 |
5.000 |
| Real Volume |
Lt |
98 |
162 |
198 |
294 |
493 |
791 |
990 |
1.487 |
1.868 |
2.486 |
3.179 |
3.757 |
4.651 |
| Weight |
kg |
51 |
69 |
77 |
101 |
154 |
226 |
260 |
391 |
447 |
514 |
698 |
801 |
895 |
| Height |
mm |
1080 |
1165 |
1310 |
1565 |
1790 |
1790 |
2085 |
1970 |
2370 |
2185 |
2265 |
2615 |
2560 |
| Shell Diameter |
mm |
590 |
590 |
590 |
650 |
750 |
980 |
980 |
1230 |
1230 |
1425 |
1615 |
1615 |
1765 |
| Insulation |
mm |
50 PU |
50 PU |
50 PU |
50 PU |
50 PU |
60 PU |
60 PU |
60 PU |
60 PU |
60 PU |
60 PU |
80 S |
80 S |
| Flow/Return Muff |
R” |
¾" |
¾" |
¾" |
1" |
1" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ½" |
1 ½" |
2" |
2" |
| Circulation |
R” |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ½" |
1 ½" |
2" |
2" |
| Cleaning Muff |
R” |
4" |
4" |
4" |
4" |
4" |
5" |
5" |
5" |
5" |
5" |
5" |
5" |
5" |
| Heater Muff |
R” |
1 ½" |
1 ½" |
1 ½" |
1 ½" |
1 ½" |
2" |
2" |
2" |
2" |
2" |
2" |
2" |
2" |
| Drain Plug |
R” |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
2" |
2" |
2" |
2" |
| Thermostat Muff |
R” |
½" |
½" |
½" |
½" |
½" |
½" |
½" |
½" |
½" |
½" |
½" |
½" |
½" |
| Anode Muff |
R” |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
1 ¼" |
PU: Polyurethane
*The right to make changes in dimension is reserved.
